Haulmax 3900 Service Truck

Elphinstone Haulmax 3900 and SVA partnership exceeds expectations

Designed and manufactured in Tasmania, the Elphinstone Haulmax 3900 is a culmination of over 25 years of experience and research into extended mine haulage applications.

Designed to operate on cycles of approximately 50km, the narrow width design of the Haulmax 3900 allows it to work effectively on roads 15 metres in width. The low centre of gravity and dual rear axle configuration is ideal for extended distance hauls in soft and slippery conditions.

Haulmax 3900 customers are operators with extended distance haulage requirements outside the range of traditional haul trucks. Based on tyre performance indices, the Haulmax design maximises vehicle payloads over longer distances.

The Cat mechanical drive power train and power shift transmission provides unmatched operating efficiency and control on steep grades, in poor underfoot conditions and on haul roads with high rolling resistance.

Pairing the Caterpillar seven-speed planetary power shift transmission with the C27 diesel engine with ACERT Technology, delivers constant power over a wide range of operating speeds.

The lock-up torque converter combines maximum rimpull and cushioned shifting of torque converter drive with the efficiency and performance of direct drive. The lock-up torque converter engages at approximately 8 km/h (5 mph), delivering more power to the wheels.

Other value-add features include excellent traction and stability, operator comfort and safety, serviceability, reliability, and an assured increase in productivity.

These features and more contribute markedly to a reduction in Cost Per Tonne (CPT) and Total Cost of Ownership (TCO) for the customer.

Elphinstone’s focus has always been to deliver customers a total haulage solution based on their specific haul requirements. Hence the 3900 can be optioned with different truck bodies to account for a variety of material applications.

Elphinstone first collaborated with Support Vehicles Australia (SVA) service modules in 2012 to produce a Haulmax 3900 service truck for a valued customer in Western Australia. The unit has since exceeded 50,000 hours in operation and still going strong.

Such was the success of the collaboration; the customer has since purchased an additional eighteen units stationed at numerous sites throughout Australia.

SVA worked closely with Elphinstone to design and manufacture the FSM70 service module to integrate seamlessly with the existing Haulmax chassis. The unique SVA hydraulic drive system is isolated from the Haulmax’s hydraulic system.

The module design and manufacturing processes consider the actual working conditions of the mining applications the Haulmax 3900 service truck will be operating in.

An engineering analysis of the Haulmax chassis’ axle loadings throughout a range of grades ensures weight distribution is kept within the safe working limits specified by Elphinstone.

The selection of the highest quality manufacturing materials and components ensure SVA modules provide safety to the operator and longevity to both the module and the Haulmax 3900.

Elphinstone’s most recent Haulmax service truck order was the 30th truck fitted with an SVA service module, and the 61st Haulmax delivered within Australia.

Elphinstone has delivered over 114 Haulmax trucks via the global Caterpillar Dealer Network to customers in Australia, New Zealand, Canada, Africa and South America. The numerous applications include a dump truck, service truck, water truck or tow tractor for a lowboy trailer.

Final two Haulmax 3900 dump trucks on route to Suriname

The final two Haulmax 3900 long haul dump trucks have left our facilities are on route to a valued customer in Suriname through Surmac in South America.

The four new trucks are in addition to the ten Haulmax 3900 dump trucks operating since 2019. Elphinstone has now sold more than 114 Haulmax 3900 trucks worldwide, all manufactured in Burnie Tasmania.

The versatile Haulmax 3900 can be configured as a dump truck, service truck, water truck or tow tractor for a lowboy trailer. With greater tyre and braking capacity, the Haulmax 3900 is designed for extended haul distances. Featuring a proven Caterpillar powertrain with a C27 engine, the Haulmax provides excellent performance, reliability and productivity for long life and a low total cost of ownership (TCO).

Please contact your local Caterpillar dealer or visit our website for more information on our products.

Elphinstone Haulmax 3900

First of Four Haulmax 3900 dispatched for Suriname

Elphinstone’s focus has always been to deliver customers a total haulage solution based on their specific haul requirements.

Prior to 2016, Surmac, an authorised dealer of Elphinstone machines in Suriname, identified a need for an extended distance haul solution for a valued customer. In September 2018, Elphinstone received an order for ten Haulmax 3900 trucks that were manufactured and commenced operation in 2019. The best voice of customer feedback is a repeat order and Elphinstone is excited to be delivering the first of four additional Haulmax 3900 dump trucks to the same valued customer in Suriname.

The versatile Haulmax 3900 can be configured as a dump truck, service truck, water truck or tow tractor for a lowboy trailer. With greater tyre and braking capacity, the Haulmax 3900 is designed for extended haul distances. Featuring a proven Caterpillar powertrain with a C27 engine, the Haulmax provides excellent performance, reliability and productivity for long life and a low total cost of ownership (TCO). A spacious ROPS/FOPS certified cabin, ergonomic controls, air suspension seats, access stairs, platforms and ground-level service points all provide a comfortable and safe operating environment.

Elphinstone Haulmax 3900 Chassis

First Elphinstone Haulmax 3900 delivered in 2008

In 2007, Elphinstone invested in Haulmax extended haul trucks and relocated the business from Brisbane to Tasmania. On December 11 2008, the first Haulmax 3900 truck was shipped to a valued customer in Western Australia and fitted with a Narwhal fuel and lube rig.
In 2014, Elphinstone purchased the remaining shares of Haulmax Pty Ltd to become 100% owners.
In 2021, the Haulmax 3900 continues to impress with expanding fleets worldwide. Elphinstone’s most recent Haulmax order will be the 30th truck fitted with SVA (Service Vehicle Australia) service modules and delivered into Western Australia. The machine is the 18th unit purchased by the customer, and the 61st Haulmax delivered within Australia. The customers’ first unit, commissioned into service on November 22 2012, is now approaching 50,000hrs and still going strong.
Haulmax 3900 SVA Service Modile

Haulmax 3900 Service Module logs over 40,000 hours since 2012

The versatile Haulmax 3900 truck from Elphinstone fitted with a Support Vehicles Australia (SVA) fuel and lube service module, sold and serviced by WesTrac to a valued customer in the Pilbara, Western Australia. A total of 17 Haulmax trucks have been delivered to the same customer since 2012, the oldest with more than 40,000 hours of strong reliable service. SVA worked with Elphinstone to integrate the 67,000L capacity module and ensure optimum load distribution on the Haulmax chassis.

Haulmax 3900 Chassis

Haulmax 3900 Chassis for Service Module

Ready for shipment to a valued customer in Western Australia, the Elphinstone Haulmax 3900 chassis will be fitted with a Service Module. The versatile Haulmax 3900 can be configured as a dump truck, service truck, water truck or tow tractor for a lowboy trailer. With greater tyre and braking capacity, the Haulmax 3900 is designed for extended haul distances. Featuring a proven Caterpillar powertrain with a C27 engine, the Haulmax provides excellent performance, reliability and productivity for long life and a low Total Cost of Ownership. A spacious ROPS/FOPS certified cabin, ergonomic controls, air suspension seats, access stairs, platforms and ground-level service points all provide a comfortable and safe operating environment.

stockton-alliance-image

Stockton Alliance

Solid Energy’s Stockton opencast coalmine is home to a whole fleet of super-sized boys’ toys… with few more impressive than the new Haulmax 3900 dumptrucks. The Stockton mine’s main haul road, the “2 to 5,” drops 400 metres along its 7.5km length. The Haulmax 3900’s rear brake swept area of over 10 square metres keeps 130 tonnes all up well under control on the downhill run.

Download Article

Haulmax 3900 Series Truck

Haulmax 3900 Series

The Haulmax 3900’s narrow width, low centre of gravity and dual rear axle configuration offers a solution for extended distance hauls and soft & slippery underfoot conditions as a prime mover for service and support mine site equipment.  Elphinstone have delivered almost 100 Haulmax trucks via the global Caterpillar Dealer Network to customers in Australia, New Zealand, Canada, Africa and South America where they are providing solutions as extended distance haul trucks, service trucks, low bed tow tractors, water trucks, and wet weather / downhill haulers.

Ride Comfort

The independent front suspension system and rear independently mounted ‘A’ frame axle assemblies, combined with a long wheel base, offers unrivalled levels of safety and comfort.

95% Genuine CAT components

Our 3900 series haul truck incorporates a complete Caterpillar powertrain, and with 95% of all serviceable parts being genuine Cat components, customers are able to take full advantage of the local product support capabilities provided by the global Caterpillar dealer network.

Elphinstone works closely with Caterpillar® to ensure matched power train components optimise longevity, reliability and mechanical availability, resulting in improved productivity and reduced operating costs.

Global Dealer Network

Haulmax trucks are sold and supported via the global Caterpillar Dealer Network providing unparalleled sales and aftermarket support.

Elphinstone endeavours to provide the latest technology. Design updates are constantly made to ensure industry expectations of reliability, safety and operator comfort are achieved.

Haulmax 3900
